Create secure, overhead spans by running high strength wire rope between two fixing points. Ideal for applications where no direct vertical anchor point is available.
Description
Designed specifically for spanning installations and bracing applications
- The light duty 3 mm version is ideal for suspending lightweight electrical services, ductwork and signage
- The heavy duty 6 mm version is perfect for suspending M&E or HVAC services, or where a long catenary is required
- Supplied as complete, ready-to-use kits, including galvanised wire rope • Cut to bespoke lengths, hex locking key and release key included
- Fast installation, reducing time spent working at height
- Quarter turn secondary locking mechanism in the Gripple fastener prevents dynamic movements
- Easily tensioned using the Gripple Catenary Tensioning Tool
5:1 safety factor for load rating free span
| No.3 | No.6 |
| Light duty 3 mm version | Heavy duty 6 mm version |
| Up to 30 kg vertical load per free span | Up to 100 kg vertical load per free span |
| Connection type: 3 mm C-Clip | Connection type: 6 mm C Clip |
| Not suitable for use with any Tensioning Tool | Can be used with the D6 Torq Tensioning Tool |
